Hotel Restaurant Micro Craft Beer Brewing Equipment 50L - 10000L Long Life

Name: Hotel Restaurant Micro Craft Beer Brewing Equipment 50L 10000L Long Life
Brand: CGET
Price: 1 USD

Wholesale Hotel Restaurant Micro Craft Beer Brewing Equipment 50L - 10000L Long Life from china suppliers

Brand Name : CGET

Model Number : Custom-design

Certification : CE UL ISO9001

Place of Origin : Shandong, China (Mainland)

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 300Set Per Years

Delivery Time : 40Work Days

Packaging Details : Shandong, China (Mainland)

Processing : Fermenting Equipment

Condition : New

Materia : Stainless steel 304/316l/316

Insulation material : Polyurethane or rock wool

Quality control : 48 hours jacket and welding joint pressure and water testing

Capacity : 50-10000l

Application : Beer brewing in hotel, restaurant, brewpub etc

Thickness of Tanks : 3mm for interior shell/2mm for exterior shell

Cooling way : Cooling belt ice water or dimple ty

Contact Now

Hotel Restaurant Micro Craft Beer Brewing Equipment 50L - 10000L Long Life

Product Description

1. Two vessels, three vessels, four vessels brewhouse available

2. Different specifications meet different needs of customers

3. Mash tank; hydrator, mixer, steam heating jacket

4. Lauter tun: rake, agitator, false bottom, hydrator

5. Brewkettle, steam heating jacket, inner steam heating deivce; direct fire

6. Whirlpool tun: whirlpool entry

7. Pumps, processing piping, valves and fittings

Mill system

80kg/h, 100kg/h, 200kg/h, 300kg/h, 500kg/h, 1000kg/h

Beer brewing system’s analysis

items	CG-0.1	CG-0.2	CG -0.3	CG -0.5	CG -1.0	CG-2.0
Production capacity	100L/day	200L/day	300L/day	500L/day	1000L/day	2000L/day
floor space	15m2	25m2	35m2	50m2	80m2	120m2
Total power	12kw	12kw	12kw	15/36kw	22/72kw	31/144kw
Maximum hourly water consumption	0.2m3/h	0.4m3/h	0.5m3/h	1.0m3/h	1.5m3/h	2.0m3/h
Total water used	0.5m3/d	1.m3/d	1.5m3/d	2.5m3/d	5m3/d	10m3/d
Consumption of malt	20kg	40kg	60kg	100kg	200kg	400kg
Consumption of hops	60g	120g	180g	300g	600g	1.2kg
Yeast	100g/1L	200g/2L	300g/3L	500g/5L	1kg/10L	2kg/20L
Maximum steam		0.017t/hour	0.017t/hour	0.05t/hour	0.10t/hour	0.20t/hour

Packaging & Shipping

1. All tanks will be packaged with soft protection material and mounted on strong carbon steel frame

2. All accessories and spare parts will be packaged with seperated box.

3. After loaded into containers, all equipments will be well fixed to the containers.

Advantages:
1. Complete, new, and high quality configuration.
2. Auxiliary systems selection of leading and imported brand.
3. The auxiliary systems are long life, high-performance, high-quality, low-loss.
4. Certified stainless steel(304,316) material for all tanks.
5. Electrical accessories reach CE, PED,LVD export standards.
6. Supporting auxiliary system voltage and frequency match your standard exactly.
7. New production technics.
8. Stable quality, high performance, strict quality control.
9. All the equipment are adopted 100%TIG welded joints, mirror Polishing.

Packaging & Delivery
Packaging Details
Micro Beer Brewery 300L 500L 1000L Brewhouse Beer Brewing Mash Tun System package:
By independent containers or by bulk carriers PVC film, or wooden case, or steel frame.
1. All tanks will be packaged with soft protection material and mounted on strong carbon steel frame
2. All accessories and spare parts will be packaged with separated box.
3. After loaded into containers, all equipment will be tightly fixed to the containers.
Port
qingdao

Product Tags:

craft beer making equipment

craft beer system

Hotel Restaurant Micro Craft Beer Brewing Equipment 50L - 10000L Long Life Images
